Viking Access Gate Openers Replacement G5 Electronic Control Board Single VA-ECUSNX2

Details

Viking Access Gate Openers Replacement G5 Electronic Control Board Single VA-ECUSNX2

Key Features:

• Adaptive motor control
• Adjustable speed control
• Anti-tailgating feature
• True battery back-up
• Built-in thermostat-controlled heater
• Two 4A batteries included
• Powder-Coated Aluminum, Rainproof Enclosure
• Lockable door
• Pre-punched holes for conduits
• UL 325 Compliant
• Two Monitoring Inputs With Up To 4 Devices Per Input
• On board display
• Built-in voltmeter
• Lightning strike protection

Technical Specifications:

• Compatible Operators: G5
• Duty Cycle: 100%
• Operating Voltage: 24VDC
• Voltage Current Specs: 120VAC - 1.5A or 240VAC - 1.0A (each motor)
• Main Power Frequency: 50Hz / 60Hz
• Main Power Fuse: 4A Timed
• Alternative Power Source: 24VAC / VDC (60VA) or Solar
• Accessory Power: 24VDC - 750mA
• Power Consumption - Sleep: 28mA
• Motor Current (Typical) 2.0A
• Operating Temperature: -20°F (-28°C) to 131°F (55°C)
• Dimensions Standard Box: (L x D x H) 16.75 x 6.125 x 15.625 in
