Viking Access I-770 Underground Swing Gate Opener (Steel Chassis) - VA-I770
Details
Viking Access I-770 Underground Swing Gate Opener (Steel Chassis) - VA-I770
The I-770 Underground Swing Gate Operator is a nearly invisible solution to home and property owners that want to minimize the visibility of their gate opener. It is capable of handling gates up to 12 ft. long and weighing up to 650 lbs., and features top-of-the-line safety standards, and is ETL Listed, UL325, and UL991-Compliant. The direct-drive DC gear-head unit is IP67 water-resistant and has a convenient manual release mechanism. The I-770 comes standard with steel chassis and a battery backup capable of 250 continuous cycles. The I-770 is powered by the V-Flex control board, including speed control and diagnostic LCD display. This intuitive operator is solar efficient and ready to be powered with low voltage wiring, allowing versatility of installations.
- Adaptive motor control
- Built-in thermostat controlled heater
- Built-in voltmeter
- Lightning strike protection
- Multiple power options
- On-board display
- True battery back-up
- UL325 compliant
- Two monitoring inputs With up to 4 devices per input
- Adjustable speed control
- Anti-tailgating feature
- Fail secure mode
- Manual release - mechanical
- Multiple power outage options
- Positive stop limits
Technical Specifications:
- Gate Type: Swinging Gate
- Max Gate Weight: 650 lbs.
- Max Gate Length: 12 ft.
- Battery Backup Capacity: 400 Full Continuous Cycles
- Max Duty Cycle: 100% Continuous Cycle
- Voltage Current: 120VAC - 1.5A or 240VAC - 1.0A (each motor)
- Main Power Frequency: 50Hz - 60Hz
- Main Power Fuse: 4A Timed
- Alternate Power Source: 24 VAC / VDC (60VA) Or Solar
- Accessory Power: 24 VDC - 750mA
- Opening Angle: 110°
- Main Power Source: 120/240 VAC Single Phase
- Operational Voltage: 24 VDC
- Operating Speed: 13 - 15 Inches Per Second / 90° Opening
- Usage Class: Class I, II, III, IV
- Operating Temperature: -20˚F up to +160˚F
| SKU | VA-I770 |
|---|---|
| Model | I-770 |
| Actuator Voltage | 24 DC |
| Max Gate Length | 12 ft. |
| Max Gate Weight | 650 lbs. |
| Input Voltage | 24 DC, 24 AC, 110/115/120 AC (60 Hz, 1 Phase), 220/230/240 AC (60 Hz, 1 Phase) |
| Operator Type | Single Gate |
| Operating Speed | 13 - 15 in. Per 90° Opening |
| Usage Class | I, II, III, IV |
| Manufacturer | Viking Access Systems |
| Warranty | 3-Year |
